43 Inch Freestanding Outdoor Directional Signage
A durable 43" freestanding directional signage solution for guiding foot traffic in outdoor public spaces.
The 43 Inch Freestanding Outdoor Directional Signage is designed to enhance wayfinding in high-traffic outdoor environments such as malls, airports, universities, and public parks. This robust, weather-resistant signage solution combines a 43-inch high-definition LCD screen with a freestanding, durable frame to display directional content, maps, and information in real time.
Built to withstand harsh outdoor conditions, the signage features a high-brightness display that ensures clear visibility even in direct sunlight. Whether used for wayfinding, event signage, or public notifications, it serves as an essential tool for guiding visitors through complex spaces, offering interactive capabilities for personalized navigation (optional). Its freestanding design makes it adaptable to various locations, and its ability to be remotely updated via a cloud-based content management system (CMS) ensures that information is always accurate and up-to-date.
Perfect for busy outdoor environments, this signage solution provides both functionality and a modern, professional look that enhances the overall visitor experience.
Key Features
43-inch high-brightness LCD screen for daylight readability
Freestanding design for easy placement in high-traffic areas
Weatherproof and durable construction for outdoor use
Remote content management via cloud-based CMS for real-time updates
Optional interactive touchscreen functionality for personalized wayfinding
High-definition resolution for clear and sharp visuals
Energy-efficient operation for long-lasting performance
Vandal-resistant materials for added security in public spaces
Flexible mounting options to accommodate various environments
Multi-zone display capabilities for showing dynamic, multi-faceted content
Power in Numbers
20
Display Types
30
Partnerships
200
Installations
Model Number
OC43-H20-FS-BW09
Screen Size
43 inch
Specifications
Panel Type | Industrial-grade A+ LCD IPS Panel |
Resolution | 1920×1080 (FHD) |
Brightness | 2000+ nits |
OS Options | Windows, Android, Linux |
Connectivity | HDMI, USB, RJ-45, Wi-Fi, 4G/5G Module |
Enclosure | Cold-rolled metal sheet, Tempered glass |
Dimensions | 2000x970x200 MM, Customizable |
Weight | 122 KG (for Reference) |
Mounting Options | Freestanding |
IP Rating | IP55, IP65 |
Heat Control | Air-cooling, Air-conditioner |
Operating Temperature | -35°C to 55°C |
Power Supply | AC 100-240V, 50/60Hz |
Power Consumption | 400W – 800W Due to heat-control system |
Download the full datasheet here
